1. Equipped with an integrated condensate vaporizer, it solves the problem of water discharge from air conditioning condensation.
2. High power heating element with a high evaporation capacity of 1200 milliliters per hour.
3. Energy saving products with a low power consumption of 120W per hour.
4. Easy to install, with no changes in the overall structure, and the vaporizer concentrated at the bottom of the air conditioner.
5. Constant temperature control, automatic adjustment of evaporation capacity, optional real-time monitoring of air conditioning operation status.
model
BCZ- 3 0 00
Power supply form
1P /220V/50HZ
Overall dimensions (mm)
Width W
43 5
High H
111 5
Thick D
2 8 0
Refrigeration capacity
3 0 00W
Operating current
9.2A _
Condensate evaporation amount
350ML/H
input power
2000W _
refrigerant
R22
work noise
70dB _ _
Protection level
Inner loop
IP 5 4
outside loop
IP 34
Temperature setting range inside the cabinet
25℃～38℃(factory setting 30 ℃ )
Operating ambient temperature range
- 25 ℃～45 ℃
Power connection method
3-core power cord (reserve 2 meters in length)
Total Weight
6 5 kg
Exterior color
RAL 7035(light gray)
Circulating air volume
Inner loop
1 2 50 m³ / h
outside loop
1 55 0m³/h
Temperature control method
Digital display temperature controller
Test conditions: Dry bulb temperature inside the electrical cabinet: 35°C, wet bulb temperature: 26°C, dry bulb temperature outside the electrical cabinet: 35°C
