Feature
1. The intelligent automatic control system is used, which can set all kinds of main parameters during production, and can deal with the posture of the machine and equipment in real time.
2. Liquid crystal display, and Chinese and English can be switched back and forth, which is convenient to operate.
3. It has a memory function, and can store the data information such as time, thickness, working pressure, speed, and schedule of the aluminum die-casting mold, which is beneficial to the next operation.
4. It has mechanical equipment to ensure the alarm function, and it is convenient for operators to detect faults immediately.
5. The high-precision electronic ruler is used to carry out the clamping inspection, and the precise positioning accuracy is high.
Specification
| Unit | LZ160 | LZ180 | LZ1100 | |
| Dieleeking Force | kN | 1600 | 1800 | 11000 |
| Inner Space Between Tie Bais(h*v) | mm | 440*440 | 480*480 | 1050*1050 |
| The Bar Diameter | mm | Φ80 | Φ85 | Φ210 |
| Diethickness(Min-Max) | mm | 200-550 | 200-550 | 450-1150 |
| Die Stroke | mm | 350 | 380 | 1000 |
| Ejection Stroke | mm | 80 | 80 | 260 |
| Ejection Force | kN | 100 | 110 | 560 |
| Injection Force (With Intensification) | kN | 180 | 220 | 930 |
| Inject Stroke | mm | 345 | 350 | 850 |
| Diameter Of Shot Sleeve | mm | 40 / 50 / 60 | 50 / 60 / 70 | 90 / 100 / 110 / 120 / 130 |
| Dosage Of Fluid Metal Pershot | kg | 0.8 / 1.2 / 1.8 | 1.2 / 1.8 / 2.5 | 10.1 / 12.5 / 15.1 / 18 / 21.1 |
| Injection Pressure(With Intensification) | MPa | 143 / 92 / 64 | 112 / 78 / 57 | 141 / 115 / 95 / 80 / 68 |
| Prjection Area Of Casting | cm² | 105 / 163 / 234 | 160 / 230 / 316 | 753 / 924 / 1122 / 1325 / 1571 |
| Max Area Of Casting | cm² | 375 | 450 | 2750 |
| Position Of Pressure Injection | mm | 0, -140 | 0, -140 | 0, -150, 300 |
| Over Height Of Flange | mm | 10-0.05 | 10-0.05 | 20-0.05 |
| Diamater Of Pressure Chamber Flange | mm | 110 | 110 | 240 |
| Plunger Penetration | mm | 120 | 130 | 300 |
| Dry Cycle | S | 7 | 7 | 18 |
| Pipe Line Pressure | MPa | 14 | 14 | 14 |
| Motor Power | kW | 11 | 11 | 30*2 |
| Volume Of Oil | L | 450 | 600 | 1800 |
| Machine Weight | kg | 6000 | 7000 | 65000 |
| Overall Dimensions(L*W*H) | m | 5*1.4*2.2 | 5.6*1.5*2.3 | 11.5*2.6*3.6 |
