Wire diameter range	φ 0.3- φ 0.7mm
Number of production head	24-36
Number of painting layers	9-13
Line spacing	6.0 - 7.0 mm
Linear speed Max	130 m/min
Oven type	Hot air circulation
Oven length	5500 mm
Annealing furnace length	9000~12000 mm
Specification of pay off reel	φ 400- φ five hundred
Wire take-up device	single axis torque take-up
Take up weight	PT10-PT60; PT25-PT270
Painting method	felt, mold, inverter control
Paint adding system	automatic liquid level adjustment paint adding box
Belt threading mode	one belt two threading mechanism
Steam system	waste discharge and waste heat utilization type
Waste gas treatment	twice catalytic combustion
Total installed power	about 155 KW
