Specification

一、install and use

1.The installation of the coupling must be according to the requirements of design, pay attention to the arrangement and multiple axis same phaseits both ends in principle all can be active or follower, but try to make the spline fit place far away from the impact vibration source or sources.

2.Clean before installation on the surface of the flange joint grease, paint, and remove the factors adverse to the faving surface.

3. The spline shaft and the spline sets of the black arrow mark to is, in case of dislocation.

4.High strength bolt flange connection.

5. lnstall a good coupling loading operation a after tighten again, repeat two classes, in case of loose.

二、maintenance and repair

1. New coupling had been add grease, do not need to immediately come on.lf the coupling of stored more than six months to go.

2. Of the coupling lubrication general use 2 ithium base grease, appropriate USES the environment of high temperature 3 or 4 calcium base greasegeneral conditions come on the continuous running 500 hours,the runtime once every three months refueling,if under the condition of high temperaturemust go once a week.

3.The normal work of the coupling, maintenance work at ordinary times only: () listen to whether there are abnormal noise; 2 whether radial runoutextraordinary:(3) whether the coupling boltlooseness, etc.

4, The maintenance period,generally in the six months to one year, maintenance check the bearing or cross shat wear and creasing, must bechanged more than 0.25 mm; With a spacer coupling, the gasket wear is more than 0.35 mm shall be replaced.

三、transportation and storage

1,With soline coupling transpor needs to be done under the condition of level, such as to upriht handling to additional protection measures.tprevent damage, pay attention to don't damage the bearing down.

2. The coupling of storage should be kept in dry place, avoid sunlight, rain, in the storage period should be avoided and acid and alkali or organicsolvent such as material put together.
