maximum speed

1850rpm

Yarn/strand diameter before twisting

0.1-0.45mm

Rope diameter MAX

1.8mm

Twist length control method

Swap gear twist control

Pulley diameter

Φ318mmX2

Braking method

Air disc brake

twist direction

Left and right twist

I-shaped wheel inside the cylinder

Φ165mm

Cylinder threading method

Tungsten steel threading nozzle

Take-up spool

Demander provides

Operation direction

left in right out

Device Enclosure Type

Totally enclosed cover

main motor power

4kw

Inverter

4kw domestic brand

low voltage button

Tadashi Tadashi

Take-up control method

chain drive

Cylinder support method

large bearing

Cradle length and control method

Chain damping cradle length 350mm

Device length, width and height

Length 7750×width 600×height 900
