maximum speed

1300

Yarn /strand diameter before twisting

0.2-0.6mm

Rope diameter MAX

2--3.5mm

Twist length control method

gear changing teeth

Pulley diameter

Φ318mmX2

Braking method

hydraulic pump brake

twist direction

Left and right twist

I-shaped wheel inside the cylinder

Φ200mm

Cylinder threading method

Ceramic threading nozzle

Take-up spool

Provided by the buyer ( Φ200-Φ400mm)

Operation direction

left in right out

Device Enclosure Type

grille

main motor power

11kw

Take-up control method

chain take-up

Cylinder support method

large bearing

Cradle length and control method

Ordinary cradle length 305mm
