maximum speed

2400rpm

Yarn/strand diameter before twisting

0.08-0.45mm

Rope diameter MAX

1.5mm

Twist length control method

Stepless pitch control (servo control)

Traction motor power

1.5Kw Servo Motor

Pulley diameter

Single traction Φ233mmX2

Braking method

Air disc brake

twist direction

Left and right twist

I-shaped wheel inside the cylinder

Φ100mm，150mm

Cylinder threading method

Tungsten steel threading nozzle

Take-up spool

B60  (255)

Operation direction

left in right out

Device Enclosure Type

Totally enclosed shield 8mm seamless tube steel plate (improved safety)

main motor power

4kw Zhima motor (energy saving)

Inverter

4kw Xinjie

touch screen

fast

PLC

fast

low voltage button

Tadashi Tadashi

Take-up control method

Torque motor take-up (4N·M) is customized according to customers

Cylinder support method

large bearing

Cradle length and control method

Chain damping cradle length 255mm

Device length, width and height

Length 7500×width 720×height 1000 (including retractable line)
