Certification:

TUV Certification 2 PfG 2693/06.19 all color

CGC Certification CGC/CF 150:2019 all color

4.0-240mm2

Technical data

Conductor :EN60228 Class 5 flexible annealed stranded copper

Insulation:90 ℃PVC insulation material with RoHS compliance

Jacket: 90 ℃ PVC sheath material with RoHS compliance

 Rated voltage:1000V DC, 1500V DC;

est voltage:1000V DC=5000V,5Min;1500V DC=5000V,5Min

Rated temperature:-40～90℃;Ambient temperature: –20°C up to +60°C
