Specification
Size | Total length | Teeth are long | Shank diameter | Eextrusion | Cutting | Squeeze (internal coolant） | Cutting (internal coolant) |
M0.8*0.2 | 34.5 | 3.8 | 3 | 100 | 95 | Can not do internal cooling | Can not do internal cooling |
M1.0*0.25 | 34.5 | 3.8 | 3 | 95 | 87 | Can not do internal cooling | Can not do internal cooling |
M1.2*0.25 | 34.5 | 3.8 | 3 | 95 | 87 | Can not do internal cooling | Can not do internal cooling |
M1.4*0.3 | 37.5 | 5 | 3 | 95.6 | 87.6 | Can not do internal cooling | Can not do internal cooling |
M1.6*0.35 | 39.5 | 7 | 3 | 96 | 88 | Can not do internal cooling | Can not do internal cooling |
M1.7*0.35 | 39.5 | 7 | 3 | 96 | 88 | Can not do internal cooling | Can not do internal cooling |
M1.8*0.35 | 39.5 | 7 | 3 | 96 | 88 | Can not do internal cooling | Can not do internal cooling |
M2*0.4 | 42.5 | 9 | 3 | 96.5 | 88.5 | Can not do internal cooling | Can not do internal cooling |
M2.3*0.4 | 42.5 | 9 | 3 | 96.5 | 88.5 | Can not do internal cooling | Can not do internal cooling |
M2.5*0.45 | 44.5 | 9 | 3 | 96.9 | 88.9 | Can not do internal cooling | Can not do internal cooling |
M2.6*0.45 | 44.5 | 9 | 3 | 96.9 | 88.9 | Can not do internal cooling | Can not do internal cooling |
M3*0.5 | 49.5 | 10 | 4 | 97.8 | 89.8 | Can not do internal cooling | Can not do internal cooling |
M3.5*0.6 | 49.5 | 10 | 4 | 97.8 | 89.8 | Can not do internal cooling | Can not do internal cooling |
M4*0.7 | 55.5 | 11 | 5 | 104.8 | 96.8 | 110.4 | 102.4 |
M5*0.8 | 65.5 | 12 | 5.5 | 138 | 128 | 147.3 | 137.3 |
M6*1.0 | 67.5 | 16 | 6 | 160.8 | 148.8 | 170.4 | 158.4 |
M7*1.0 | 70 | 19 | 6 | 194.1 | 180.1 | 207.6 | 193.6 |
M8*1.0 | 70 | 19 | 6.2 | 228.1 | 212.1 | 245.5 | 229.5 |
M8*1.25 | 70 | 19 | 6.2 | 228.1 | 212.1 | 245.5 | 229.5 |
M10*1.0 | 75 | 22 | 7 | 306.2 | 286.2 | 334.9 | 314.9 |
M10*1.25 | 75 | 22 | 7 | 306.2 | 286.2 | 334.9 | 314.9 |
M10*1.5 | 75 | 22 | 7 | 306.2 | 286.2 | 334.9 | 314.9 |
M12*1.0 | 82 | 29 | 8.5 | 405 | 381 | 452 | 428 |
M12*1.25 | 82 | 29 | 8.5 | 405 | 381 | 452 | 428 |
M12*1.5 | 82 | 29 | 8.5 | 405 | 381 | 452 | 428 |
M12*1.75 | 82 | 29 | 8.5 | 405 | 381 | 452 | 428 |
M14*1.0 | 88 | 26 | 10.5 | 511.2 | 483.2 | 578.9 | 550.9 |
M14*1.25 | 88 | 26 | 10.5 | 511.2 | 483.2 | 578.9 | 550.9 |
M14*1.5 | 88 | 26 | 10.5 | 511.2 | 483.2 | 578.9 | 550.9 |
M14*2.0 | 88 | 26 | 10.5 | 511.2 | 483.2 | 578.9 | 550.9 |
M16*1.0 | 95 | 26 | 12.5 | 635.3 | 603.3 | 729.8 | 697.8 |
M16*1.25 | 95 | 26 | 12.5 | 635.3 | 603.3 | 729.8 | 697.8 |
M16*1.5 | 95 | 26 | 12.5 | 635.3 | 603.3 | 729.8 | 697.8 |
M16*2.0 | 95 | 26 | 12.5 | 635.3 | 603.3 | 729.8 | 697.8 |
