Specification

_{PRODUCT DESCRlPTION
1. Rate temperature: 125℃,150℃
2. Rate voltage: 1140V
3. Standard: Q/320217HZJL01-2010
4. Stranded,tinned or bare copper conductor 0.5～95
5. XLPE insulation, ROHS、REACH compliant.
6. Uniform insulation thickness to ensure easy stripping and cutting
7. For lead wiring of B F H insulation class motor.}

_{CABLE CONSTRUCTION}

CONDUCTOR/导体			INSULATION/绝缘		MAX.COND.RESISTANCE 最大导体电阻（Ω/km,20℃,DC)	DIELECTRIC STRENGTH 耐压强度（VAC,1min)
规格（mm2)	CONSTRUCTION 构造（No./mm)	DIA. 外径 (mm)	THICKNESS 厚度（mm）	O.D.外径（mm）	MAX.COND.RESISTANCE 最大导体电阻（Ω/km,20℃,DC)	DIELECTRIC STRENGTH 耐压强度（VAC,1min)
0.50	16/0.20	0.92	0.70	2.45	40.1	3000
0.75	24/0.20	1.13	0.70	2.60	26.7	3000
1.0	32/0.20	1.31	0.70	2.80	20.0	3000
1.5	30/0.25	1.58	0.80	3.25	13.7	3000
2.5	49/0.25	2.02	0.80	3.80	8.21	3000
4.0	56/0.30	2.60	0.80	4.30	5.09	3000
6.0	84/0.30	3.42	0.90	5.40	3.39	3000
10	84/0.40	4.56	1.00	6.50	1.95	3000
16	126/0.40	5.60	1.15	8.30	1.24	3000
25	196/0.40	6.95	1.15	9.50	0.795	3000
35	276/0.40	8.74	1.15	11.20	0.565	3000
50	396/0.40	10.46	1.40	13.60	0.393	3000
70	360/0.50	12.50	1.40	15.60	0.277	3000
95	475/0.50	13.73	1.60	17.40	0.210	3000
