Type:Vertical,1-Cylinder,4-Stroke, Air Cooled.
Combustion System:Direct Injection.
Rated Power(HP/rpm):13.9/3000.
Starting System:Electric Starter.
Specification
Model | YD1100FE |
Type | Vertical, 1-Cylinder, 4-Stroke, Air Cooled |
Combustion System | Direct Injection |
BorexStroke(mm) | 100x85 |
Displacement(cc) | 668 |
Compression Ratio | 19:01 |
Rated Speed(rpm) | 3000 |
Rated Power KW/rpm | 10.2/3000 |
Rated Power HP/rpm | 13.9/3000 |
Starting System | Electric Starter |
Fuel Tank(L) | 5.5 |
Lube(L) | 2.0 |
Fuel Consumpition(g/kwh) | 275 |
Fuel | 0#(Summer), -10#(Winter) diesel oil |
Lube | SAE10W30(Above CD grade) |
Overall Dimension(mm,LxWxH) | 445x470x540 |
Net Weight(kg) | 62 |
Rotation Direction(View from Flywheel) | Clockwise |
