Compact structure, flexible and convenient production,energy saving and coating saving. It is the preferred model for grooved hexagonal inner workpiece.
Specification
| Equipment model | The basket size | Loading capacity | motor power | The centrifugal rotational speed | Tilt Angle | Workpiece reference range | Coating loading capacity |
| ZZ-300II | φ350mm,H=350mm | 20KG | 4KW | 0-350r/min(正反转) | ≤65° | M4*10-M20*100 | 50L±5L |
| ZZ-400II | 中450mm,H=350mm | 30KG | 4KW | 0-350r/min(正反转) | ≤65° | M5*10-M20*120 | 70L±5L |
| ZZ-500II | φ550mm,H=350mm | 45KG | 5.5KW | 0-350r/min(正反转) | ≤65° | M5*10-M20*120 | 90L±5L |
