Maximum Allowable Feed Thickness: 3mm.
Maximum Allowable Feed Width: ≤500mm.
75KW frequency conversion motor.
Controlled by frequency converter to achieve stepless speed regulation.
Specification
| Maximum Allowable Feed Thickness | 3mm |
| Maximum Allowable Feed Width | ≤500mm |
| Host Power | 75KW frequency conversion motor, controlled by frequency converter to achieve stepless speed regulation |
Matching Reducer Model | JZQ650 |
Transmission Form Of Main Motor And Reducer | flanged nylon pin coupling |
Transmission Form Of Reducer And Transfer Gearbox | 1 1/4" sprocket coupling |
| Material | Mpa700 slitted coil |
Transfer Gearbox (Lower Single Shaft Rotation) | The first, second and last pair of upper and lower shafts are fully active. (with 6 vertical roller racks) |
| Bevel Gear Module | M9, teeth number: Z20 |
Bevel Gear Material | 40Cr |
Tooth Surface Induction Hardening | HRC52~55 |
| Input Shaft Diameter | Φ65 |
| Output Shaft Diameter | Φ50 |
| Transfer Gear Box Material | HT200 |
Rack Front And Rear Center Distance | 650mm |
| Coupling Between Transfer Gearboxes | 1 1/4" x 16 tooth sprocket coupling |
| Frame Material | ductile iron |
Roller Die Shaft Diameter | Φ100mm, material: 40Cr |
| Quenching And Tempering | HB230~250, two-end bearing gear Φ80 |
Inside Bearing | 30216, 2 pieces |
| Outer Bearing | 6018, 2 pieces |
| Transmission Form Of Rack Roller And Transfer Gearbox | Dongfeng EQ140 drive shaft |
