Type: singer-cylinder, vertical, 4-stroke, direct injection, air-cooled diesel.
Maximun Output: 7.6KW.
Starting Model: recoil start.
Cooling Type: force air-cooled.
Specification
| Model | 4 inch, DWP100 |
| Suction Port Diameter(mm) | 100 |
Discharge Port Diameter(mm) | 100 |
| Max Suction Head(m) | 8 |
| Total Head(m) | 31 |
| Max Flow Rate(L/min) | 1600 |
| Starting Model | recoil start |
| New Weight(kg) | 73 |
| Packing Dimensions(mm,LxWxH) | 710x555x655 |
| Engine Model | 186FA(E) |
| Type | singer-cylinder, vertical, 4-stroke, direct injection, air-cooled diesel |
| BorexStroke(mm) | 86x72 |
| Engine Speed(rpm) | 3600 |
| Displacement(cc) | 418 |
| Continuous Output(KW) | 6.9 |
| Maximun Output(KW) | 7.6 |
| Cooling Type | force air-cooled |
