Better speed versus torque characteristics.
High dynamic response.
High efficiency.Long operating life.
Noiseless operation.
Higher speed ranges.
OEM & ODM service.
Sample available.
Description
| Hall Effect Angle | 120 Degree Electrical Angle | Phase | 3, 3-phase |
| Environmental Conditions | -20℃~50℃ | Axial Run Out | 0.025mm |
| Magnet Material | NdFeB | Insulation Class | Class B |
| Insulation Resistance | 100MΩmin 500VDC | Protection Class | IP44 |
Specification
| Motor Model | 80BLS105WD4845 | 80BLS105WD4830 | 80BLS106WD4830 | 80BLS126WD4830 | |
| Number of Poles | 4 | 4 | 4 | 4 | |
| Voltage | VDC | 48 | 48 | 48 | 48 |
| Rated Speed | rpm | 4500 | 3000 | 3000 | 3000 |
| Rated Torque | N.m | 0.85 | 1.6 | 1.75 | 2.38 |
| Rated Current | Amps | 10.8 | 14.8 | 2.5 | 3.1 |
| Rated Power | Watt | 400 | 500 | 550 | 750 |
| Max Torque | N.m | 0.15 | 0.1 | 0.59 | 0.63 |
| Back Emf | V / Krpm | 7.5 | 7.5 | 43.8 | 46.6 |
| Rotor Inertia | Kg.mm2 | 53 | 53 | 53 | 65 |
| Body Length | mm | 105 | 105 | 106 | 126 |
| Weight | kg | 2 | 2 | 2.1 | 2.7 |
Application
Consumer electronics
Transport
Heating and ventilation
Industrial engineering
Production
