Specifications

Model	YTE-1010B	YTE-1210	YTE-1015	YTE-1215	YTE-1325A	YTE-1530
Material Thickness	0-1.0mm	0-1.0mm	0-1.0mm	0-1.0mm	0-2.0mm	0-1.0mm
Material Width	120mm	120mm	120mm	120mm	200mm	200mm
Stacking Weight	1000kg	1000kg	1500kg	1500kg	2500kg	3000kg
Stacking Height	500mm	500mm	500mm	500mm	800mm	1000mm
Outer Diameter Of Coil	￠1000mm	￠1200mm	￠1000mm	￠1200mm	￠1300mm	￠1500mm
Motor	1/2HP	1/2HP	1/2HPX2	1/2HPX2	2HP	3HP
Feeding Speed	30m/min	30m/min	30m/min	30m/min	30m/min	30m/min
Power	AC Three Phase /380V
Mechanical Weight	220kg	250kg	300kg	350kg	1000kg	800kg

Product Description

1. Double ended feeder is used for feeding, which is 0~30m per minute, and the speed can be adjusted at will.

2. The coiled materials can be stacked to reduce the number of fillers and save the refueling time.

3. Easy to operate, solid structure, with high-speed punch, it can give full play to its advantages.
