Specifications
| Model | Maximum Feeding Width | Maximum Feeding Length | Applied Material Width | Mold Line Height | Maximum Feeding Speed | Servo Motor |
| NCF-200 | 200mm | 9999.99mm | 0.2-3.2mm | 70-170mm | 20m/min | AC0.75KW |
| NCF-300 | 300mm | 9999.99mm | 0.2-3.2mm | 70-170mm | 20m/min | AC0.85KW |
| NCF-400 | 400mm | 9999.99mm | 0.2-3.2mm | 70-170mm | 20m/min | AC1.3KW |
| NCF-500 | 500mm | 9999.99mm | 0.2-3.2mm | 70-170mm | 20m/min | AC1.3KW |
| NCF-600 | 600mm | 9999.99mm | 0.2-3.2mm | 70-170mm | 20m/min | AC1.8KW |
| NCF-700 | 700mm | 9999.99mm | 0.2-3.2mm | 90-190mm | 20m/min | AC1.8KW |
| NCF-800 | 800mm | 9999.99mm | 0.2-3.2mm | 90-190mm | 20m/min | AC2.9KW |
Product Description
High precision feeding: With the advent of high-tech industry, computer closed-circuit feedback control is used to ensure the accuracy within ± 0.02mm.
Staged feeder: 20 groups of different feeding lengths can be input, and each group provides 999 punching times to meet the processing and production of special products (optional).
Humanized manual mode: the user can input 3 sections of suitable manual speed to make it easier for the user to operate, so that the material can be accurately sent into the mold for positioning.
High efficiency release device: with the cam signal of the press and simple material thickness adjustment, you can quickly set the release angle.
Setting of feeding length: directly input the feeding length on the control panel to reach the required feeding distance.
Feeding mechanism: hollow roller, light weight, small rotary inertia, surface hardness HRC60 ° hard chrome plating, wear resistance, long service life.
