The company is specialized in producing single-station and double-station full-automatic horizontal caseless molding machine, full-automatic assembly line and full-automatic annular casting line. Please contact us if necessary.
Specification
| Model | QJ60-70TB | QJ70-70TB |
| Molding machine size (mm) L X B X H | 3500x2000x3500 | 3957x2345x4598 |
| Net weight of molding machine | 9200 kg | 9600 kg |
| Sand mold size (mm) L X B X H | 700x600x500 | 700x700x500 |
| Weight of sand mold | Approx. 224 kg/mould | Approx. 328 kg/mould |
| Modeling speed | 40 sec/mod (90 mold/hour) excluding core setting time | 40 sec/mod (90 mold/hour) excluding core setting time |
| Sand consumption | Approx. 20t/H | 29.5 t/H |
| Control mode | Touch screen/PLC full-automatic program control | Touch screen/PLC full-automatic program control |
| Supply pressure | 0.6 MPa | 0.6 MPa |
| Air supply is provided | > 3 m3/min | > 3 m3/min |
| The air storage tank is equipped | Total 2m3 (1m3 * 2) | Total 2m3 (1m3 * 2) |
| Use the power supply | AC 380V, 28kW | AC 380V, 30kW |
| Number of gates and risers | 23 | 23 |
| Gate and riser diameter | 30-35 mm | 30-35 mm |
| Drive mode | Hydraulic System Air & Pneumatic | Hydraulic System Air & Pneumatic |
| Modeling mode | Airflow sand + extrusion | Airflow sand + extrusion |
| Mold type | Aluminum double-side molding di | Aluminum double-side molding di |
