To add the signal from pyrometer to video cable, thus, operators can monitor viewing and temperature together in one screen.
These two systems share on housing and actuator, it will save lots of energy.
Feature
Pyrometer adding: the screen will show both viewing images and temperature result.
Wall type and endoscopy: operators can adjust the length of probe which put inside.
Cylinder all-in-one actuator: sealed probe, all-in-one cylinder.
Coaxial video temperature control: video cable can transfer both control and temperature signal.
LCD display:7’’high digital LCD display will help operation and maintenance at site.
Housing inside temperature: probe inside temperature will shown on the monitor.
Specification
| Pyrometer Parameters | Camera Parameters | ||
| Temperature Range | 600～1200℃ | Analog Resolution | 700～1200 lines |
| Accuracy | ±1%FS, repeatability | Network Resolution | 1.3-2 mega pixel |
| Resolution | 1℃ | Optical Zoom | 5～10x |
| Emissivity | 0-0.99 | Digital Zoom | 10-30x |
| Testing Mode | Instantaneous value/ max.value / average value | Communication Mode | coaxial video temperature control |
| Hint | Limit alarm. Abnormal temperature testing alarm. | Cooling Mode | Air cooling only / air & water cooling |
| D:S | 120 : 1 | Actuator Mode | Pneumatic or motorized |
| Focusing Range | 0.6m～∝Infinity | Furnace Max Temperature | 2000℃ |
| Min.Object | ＞Φ5mm | Retraction System | temperature, pressure, flow |
| Power Supply | 15～24VDC | Air Inlet Pressure | ≧0.3Mpa |
| Power Consumption | 150mA (max) | Air Consumption | ≈20m3 |
| Output | 4～20mA、1～5V、RS485 | Power Consumption | Pneumatic 5W，motorized 80W |
