The interlayer and mixing shaft of the machine are heated at the same time, with large heat transfer surface and high thermal efficiency.
The mixing shaft of the machine can rotate in a positive and reverse direction, so that the material can form a continuous circulation state in the cylinder, further improving the uniformity of material heating.
The mixing shaft of the machine adopts spiral distribution, so that the slurry, paste and paste materials can be dried smoothly.
Specification
| Project | Model | ||||||
| Name | Company | ZB-500 | ZB-750 | ZB-1000 | ZB-1500 | ZB-2000 | ZB-3000 |
| Working volume | L | 300 | 450 | 600 | 900 | 1200 | 1800 |
| Heating area | M2 | 6 | 7.6 | 9.3 | 12.3 | 14.6 | 19.3 |
| Stirring speed | rpm | 6-30 Stepless speed regulation | |||||
| Power | kw | 4 | 5.5 | 5.5 | 7.5 | 11 | 15 |
| Design pressure of interlayer | MPa | ≤0.3 | |||||
| Pressure in cylinder | MPa | -0.25 | |||||
Application
The following materials shall be dried in pharmaceutical, food, chemical and other industries:
Suitable for paste, paste and powder materials.
Heat sensitive materials requiring low humidity drying.
Easily oxidized, explosive, strongly irritating and highly toxic materials.
Materials requiring recovery of organic solvents.
Feature
1.The interlayer and mixing shaft of the machine are heated at the same time, with large heat transfer surface and high thermal efficiency.
2.The mixing shaft of the machine can rotate in a positive and reverse direction, so that the material can form a continuous circulation state in the cylinder, further improving the uniformity of material heating.
3.The mixing shaft of the machine adopts spiral distribution, so that the slurry, paste and paste materials can be dried smoothly.
