Manufactured with imported reed switches from Japan with long service life.
Its waterproof junction box has a minimum protection level of IP65, which can perfectly protect electrical circuits.
The control circuit is completely isolated from the measured medium.
It can realize liquid level control under high temperature and high pressure.
Multi-point remote control can be realized as needed.
Wide application range: water treatment, chemical industry, food, medicine, packaging, electronics, shipbuilding, textile, hydraulic pressure and other industries can be used.
Specification
| Working Power | 24VDC power( standard) / 220 VAC |
| Power | Max 7W |
| Contact rating | 3A / 220VAC0 SPDT |
| Extension Time | Adjustable |
| Acidity | Acid and alkali resistance |
| Working Temperature | -40~80°C |
| Protection Class | IP65 |
| Process Temperature | Standard / high |
| Wetted Material | SUS304, SUS316L, PP, PVDF |
| Process Connection | Thread / flange |
Diagram
