Specification
| model | GTLZ1013-Q | GTLZ1213-Q | GTLZ1413-Q | |
| size | ||||
| Overall length - L | mm | 2530 | 2531 | 2532 |
| Full width - K | mm | 1350 | 1351 | 1352 |
| Overall width (low) K 1 | mm | 1780 | 1781 | 1782 |
| Overall height - H | mm | 2835 | 2965 | 3075 |
| Overall height (low) | mm | 2432 | 2562 | 2672 |
| Rated working height | M | 10.3 | 12.3 | 14.3 |
| Maximum platform height | M | 8.3 | 10.3 | 12.3 |
| Maximum platform extension | mm | 900 | 900 | 900 |
| Platform size | mm | 2280x1136x1260 | 2280x1136x1260 | 2280x1136x1260 |
| performance | ||||
| Maximum number of passengers (indoor) | 2 | 2 | 2 | |
| Maximum number of passengers (outdoor) | 1 | 1 | 1 | |
| Minimum turning radius | M | 2.65 | 3.65 | 4.65 |
| Minimum ground clearance | mm | 70 | 70 | 70 |
| Rated platform load | kg | 250 | 250 | 250 |
| Platform lifting speed | cm / min | 51 | 60 | 70 |
| Platform descent speed | cm/min | 39 | 45 | 55 |
| Travel speed (high speed) | km/h | 1.5-2 | 1.5-2 | 1.5-2 |
| Travel speed (low speed) | km/h | 0.8-1.2 | 0.8-1.2 | 0.8-1.2 |
| Maximum climbing angle | % | 36% | 36% | 36% |
| power | ||||
| Battery capacity | AH | 8x6V(200AH) | 8x6V(200AH) | 8x6V(200AH) |
| charger | Amp | 90-230V AC/30A | 90-230V AC/30A | 90-230V AC/30A |
| Tilt limit angle | 。 | ±17° left and right | ±17° left and right | ±17° left and right |
| 。 | Front and rear 15°/-20° | Front and rear 15°/-20° | Front and rear 15°/-20° | |
| weight | ||||
| Machine quality | kg | 3300 | 3503 | 3670 |
