Specification
| model | 3NPZ-3800 |
| size | |
| Machine length | 3270mm |
| Full width | 1440mm |
| Overall height | 1438mm |
| Maximum working height | 5.8m |
| Maximum platform height | 3.8m |
| Platform size | 680x720mm |
| performance | |
| Rated load | 250kg |
| Minimum turning radius | 2.5m |
| Minimum ground clearance | 120mm |
| Track width | 230mm |
| Frame gauge | 1170mm |
| Track ground length | 1440mm |
| Platform lifting speed | 80mm/sec |
| Platform descent speed | 70mm/sec |
| Travel speed (maximum) | 2.2 km/h |
| Maximum adaptive slope (horizontal) | 8.5° |
| power | |
| Drive type | Crawler double-sided drive |
| Speed Shifting Mechanism | Differential steering continuously variable transmission |
| Drive motor | XYQ-3-5/8.3KW |
| Battery capacity | 51.2V DC(156AH) |
| charger | 30A |
| Tilt limit angle | ±15° left and right |
| weight | |
| Machine quality | 2600kg |
