Disk electrostatic spraying area
Disk electrostatic automatic spraying equipment
Introduction to Disk Electrostatic Automatic Spraying Equipment: Spraying room+'Ω' rotary coating is an efficient, widely applicable, and low-cost spraying method. The workpiece runs along the 'Ω' shaped track through a suspended conveyor line, and the rotary cup can move up and down according to the actual needs of the workpiece.
Spraying room+"Ω" rotary coating is an efficient, widely applicable, and low-cost spraying method, where the workpiece is transported along the suspended conveyor line The Ω shaped track runs around the rotary cup, and the rotary cup can move up and down according to the actual needs of the workpiece. Due to the workpiece's rotation, the spraying is uniform, making it suitable for workpieces that are difficult to spray on some surfaces without rotation. ② The structure is simple, with small inlet air volume and air pressure, and low coating loss. ③ The energy consumption is low, and the operating cost is low.
The Ω electrostatic spray booth uses a high-speed rotating disc spray gun to atomize and spray paint onto the workpiece under the action of an electrostatic field. During the continuous rotation of the workpiece through the Ω track and the upward and downward movement of the disc, evenly apply paint to all parts of the workpiece
Composition of Ω electrostatic spraying room: conveyor track, lifting device, hydraulic control station, discformer, power supply system, electrostatic generating paint, control system, etc
Compared with traditional operations, the DISK automatic electrostatic spray painting equipment has a coating utilization rate of over 95%, can save 30-60% of paint, and has high production efficiency. The application efficiency of electrostatic spray painting is high, and the paint mist is very small. Can greatly reduce production costs; Combined with the water curtain type DISK spraying room, cleaning has become an easy and simple task, greatly reducing environmental pollution. Due to the rotation of the workpiece, the spraying is uniform, suitable for workpieces that are difficult to spray on some surfaces without rotation; ② Simple structure, low air intake and pressure, and low paint loss; ③ Low energy consumption and low operating costs
Suzhou Gelda Machinery Disk Electrostatic Automatic Spraying Equipment Price: Specific design based on customer's actual situation, quotation process: telephone or online appointment, engineer on-site inspection, formulation of plans, and providing reasonable plan prices
