Mechanical Seals

•

  HCH-22

  Technical parameters:

  Sealing chamber temperature: -20 ℃+180 ℃

  Sealing chamber pressure: ≤ 12bar

  Linear speed: ≤ 10m/s

  Material combination:

  Sealing surface: graphite, reactive silicon carbide, pressureless silicon carbide, tungsten carbide

  Auxiliary sealing: nitrile rubber, fluorine rubber, ethylene propylene rubber

  Spring and metal parts: 304316

  contact us
•

  HCE2

  Technical parameters:

  Sealing chamber temperature: -20 ℃+180 ℃

  Linear speed: ≤ 30m/s

  Sealing chamber pressure: ≤ 15bar

  Material combination:

  Sealing surface: graphite, reactive silicon carbide, pressureless silicon carbide, tungsten carbide

  Auxiliary sealing: nitrile rubber, fluorine rubber, ethylene propylene rubber, perfluorocarbon rubber

  Spring and metal parts: 304316, Hastelloy alloy

  contact us
•

  HCEW

  Technical parameters:

  Sealing chamber temperature: -20 ℃+150 ℃

  Linear speed: ≤ 20m/s

  Sealing chamber pressure: ≤ 15bar

  Material combination:

  Sealing surface: graphite, reactive silicon carbide, pressureless silicon carbide, tungsten carbide

  Auxiliary sealing: nitrile rubber, fluorine rubber, ethylene propylene rubber, perfluorocarbon rubber

  Spring and metal parts: 304316, Hastelloy alloy

  contact us
•

  HCLL9DJUE

  Product features:

  The series pump is sealed with dry gas, and the flushing scheme often adopts Plan11/21+Plan72+76. The medium will not leak into the atmospheric environment. Usually, minor internal leaks need to be discharged into the flare system. When used in media with saturated vapor pressure lower than atmospheric pressure such as aromatic hydrocarbons and acetic acid, the flushing plan often adopts Plan 11/21+Plan 72+75

  Typical applications: pumps for light hydrocarbons, aromatics, ethylene oxide, acetic acid, etc. in industries such as petrochemical and coal chemical.

  Technical parameters:

  Sealing chamber temperature: -40 ℃+176 ℃

  Linear speed: ≤ 25m/s

  Sealing chamber pressure: ≤ 60bar

  Material combination:

  Sealing surface: graphite, reactive silicon carbide, pressureless silicon carbide, tungsten carbide

  Auxiliary sealing: nitrile rubber, fluorine rubber, ethylene propylene rubber, perfluorocarbon rubber

  Spring and metal parts: 304316, Hastelloy alloy

  contact us
•

  HCM461K-D/M461KL-D

  Technical parameters:

  Sealing chamber temperature: -40 ℃+200 ℃

  Linear speed: ≤ 5m/s

  Sealing chamber pressure: ≤ 16bar

  Shaft diameter size: 40-160mm

  Material combination:

  Sealing surface: graphite, reactive silicon carbide, pressureless silicon carbide, tungsten carbide

  Auxiliary sealing: nitrile rubber, fluorine rubber, ethylene propylene rubber, perfluorocarbon rubber

  Spring and metal parts: 304316, Hastelloy alloy

  contact us
•

  HC5615

  Technical parameters:

  Sealing chamber temperature: -30 ℃+205 ℃

  Linear speed: ≤ 25m/s

  Sealing chamber pressure: ≤ 16bar

  Shaft diameter size: 24-75mm or 1 "-3"

  Material combination:

  Sealing surface: graphite, reactive silicon carbide, pressureless silicon carbide, tungsten carbide

  Auxiliary sealing: nitrile rubber, fluorine rubber, ethylene propylene rubber, perfluorocarbon rubber

  Spring and metal parts: 304316, Hastelloy alloy

  contact us
•

  HC5620

  Technical parameters:

  Sealing chamber temperature: -30 ℃+205 ℃

  Linear speed: ≤ 25m/s

  Sealing chamber pressure: ≤ 21bar

  Shaft diameter size: 24-140mm (1 "-5.5")

  Material combination:

  Sealing surface: graphite, reactive silicon carbide, pressureless silicon carbide, tungsten carbide

  Auxiliary sealing: nitrile rubber, fluorine rubber, ethylene propylene rubber, perfluorocarbon rubber

  Spring and metal parts: 304316, Hastelloy alloy

  contact us
•

  HCCartex-DN

  Technical parameters:

  Sealing chamber temperature: -50 ℃+204 ℃

  Linear speed: ≤ 23m/s

  Sealing chamber pressure: ≤ 20bar

  Shaft diameter size: 25-100mm

  Material combination:

  Sealing surface: graphite, reactive silicon carbide, pressureless silicon carbide, tungsten carbide

  Auxiliary sealing: nitrile rubber, fluorine rubber, ethylene propylene rubber, perfluorocarbon rubber

  Spring and metal parts: 304316, Hastelloy alloy

  contact us
•

  HCCDSA

  Technical parameters:

  Sealing chamber temperature: -20 ℃+220 ℃

  Linear speed: ≤ 16m/s

  Sealing chamber pressure: ≤ 25bar

  Shaft diameter size: 24-125mm

  Material combination:

  Sealing surface: graphite, reactive silicon carbide, pressureless silicon carbide, tungsten carbide

  Auxiliary sealing: nitrile rubber, fluorine rubber, ethylene propylene rubber, perfluorocarbon rubber

  Spring and metal parts: 304316, Hastelloy alloy

  contact us
•

  HCHR

  Technical parameters:

  Sealing chamber temperature: -20 ℃+160 ℃

  Linear speed: ≤ 10m/s

  Sealing chamber pressure: ≤ 16bar

  Shaft diameter size: 20-250mm

  Material combination:

  Sealing surface: graphite, reactive silicon carbide, pressureless silicon carbide, tungsten carbide

  Auxiliary sealing: nitrile rubber, fluorine rubber, ethylene propylene rubber, perfluorocarbon rubber

  Spring and metal parts: 304316, Hastelloy alloy

  contact us
•

  HCLY9SA

  Technical parameters:

  Sealing chamber temperature: -40 ℃+200 ℃

  Linear speed: ≤ 23m/s

  Sealing chamber pressure: ≤ 20bar

  Shaft diameter size: 30-110mm

  Material combination:

  Sealing surface: graphite, reactive silicon carbide, pressureless silicon carbide, tungsten carbide

  Auxiliary sealing: nitrile rubber, fluorine rubber, ethylene propylene rubber, perfluorocarbon rubber

  Spring and metal parts: 304316, Hastelloy alloy

  contact us
•

  HC2100

  Technical parameters:

  Sealing chamber temperature: -40 ℃+150 ℃

  Linear speed: ≤ 15m/s

  Sealing chamber pressure: ≤ 16bar

  Shaft diameter size: 10-100mm

  Material combination:

  Sealing surface: graphite, reactive silicon carbide, pressureless silicon carbide, tungsten carbide

  Auxiliary sealing: nitrile rubber, fluorine rubber, ethylene propylene rubber, tetrapropylene fluorine rubber

  Spring and metal parts: 304316

  contact us
•

  HCBIA

  Technical parameters:

  Sealing chamber temperature: -20 ℃+120 ℃

  Linear speed: ≤ 15m/s

  Sealing chamber pressure: ≤ 10bar

  Shaft diameter size: 14-90mm

  Material combination:

  Sealing surface: graphite, reactive silicon carbide, pressureless silicon carbide, tungsten carbide

  Auxiliary sealing: nitrile rubber, fluorine rubber, ethylene propylene rubber, tetrapropylene fluorine rubber

  Spring and metal parts: 304316

  contact us
•

  HCMG1

  Technical parameters:

  Sealing chamber temperature: -20 ℃+120 ℃

  Linear speed: ≤ 10m/s

  Sealing chamber pressure: ≤ 12bar

  Shaft diameter size: 10-100mm

  Material combination:

  Sealing surface: graphite, reactive silicon carbide, pressureless silicon carbide, tungsten carbide

  Auxiliary sealing: nitrile rubber, fluorine rubber, ethylene propylene rubber, tetrapropylene fluorine rubber

  Spring and metal parts: 304316

  contact us
•

  HC606

  Technical parameters:

  Sealing chamber temperature: -20 ℃+425 ℃

  Linear speed: ≤ 25m/s

  Sealing chamber pressure: ≤ 25bar

  Shaft diameter size: 0.75 "-3.75"

  Material combination:

  Sealing surface: graphite, reactive silicon carbide, pressureless silicon carbide, tungsten carbide

  Auxiliary seal: flexible graphite

  Spring and metal parts: 304316, AM350, HAST.C, In718, Ti
